Xprinter XP-420B Barcode Printer
Xprinter
Xprinter, XP-420B, Barcode Printer,
Printer Design:
XP-420B is a new model of Xprinter 4-inch label printer. The cover design looks very elegant. Compact design while maintaining a large paper container. One multi-functional button and one two-color indicator, simple operation.
Application Scope:
OEMs for Xprinter printers are widely used in the manufacture of printing presses. With a wealth of manufacturing experience and strong production capacity, Xprinter can provide professional solutions that meet the actual needs of our customers.
Printer Advantages:
The Xprinter 4-inch thermal receipt printer is manufactured with high precision and reflects advanced technology.
This product is non-slip. The ergonomic design provides grip and maximum surface friction.
This product is used in various industries. This significantly reduces labor intensity, frees people from dangerous work and increases productivity.
Specifications:
| Printing | |
| Printing Method | Direct Thermal |
| Resolution | 8 dots/mm(203 DPI) |
| Interface | USB2.0 (Standard)/Lan(Optional)/Bluetooth(Optional)/WIFI(Optional)/Peel off model(Optional) |
| Optional accessories | TF card slot, RTC clock, peel off module, Cutter module |
| Max Print Speed | 152 mm (6")/s |
| Max Print Width | 108mm (4.25”) |
| Max Print Length | 1778mm |
| Media Type | Continuous, gap, black mark, fan-fold and punched hole |
| Media Width | 20 mm ~ 115 mm |
| Media Thickness | 0.06 mm ~ 0.25 mm |
| Media Length | 10 mm ~1778 mm |
| Paper roll diameter | 25.4 ~ 76.2 mm (1" ~ 3") |
| Paper thickness | 0.06 mm ~ 0.25 mm |
| Label Roll Capacity | 127 mm (5”) external diameter |
| Memory | 8MB Flash Memory |
| 8MB SDRAM | |
| Micro SD card reader for Flash memory expansion, up to 4GB | |
| Sensor | Gap sensor |
| Printer Head opened sensor | |
| Black mark sensor | |
| Processor | 32-bit RISC CPU |
| Power Supply | Input: AC 100-240V; Output: DC 24V/2.5A |
| Barcode | 1D barcode: Code 39, Code 93, Code 128UCC, Code 128, subsets A, B, C, Codabar, Interleaved 2 of 5, EAN-8,EAN-13, EAN-128, UPC-A, UPC-E, EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code11 |
| 2D barcode: PDF-417, Maxicode, DataMatrix, QR code, Aztec | |
| Emulation | TSPL \ EPL \ ZPL \ DPL |
| Dimension | 215 mm x 178 mm x 155 mm |
| Weight | 1.31 kg |
| Safety Standard | FCC, CE, CB, CCC |
| Environment | Operation condition: -10 ~ 50℃ (14 ~ 122 °F) ,10 ~ 90% non-condensing Storage condition : -40 ~ 60℃ (-40 ~ 140 °F), 10 ~ 90% non-condensing |
