Syble

XB-S60

CCD barcode scanner

It used in Non-food specialty stores such as Fashion Clothes, Cosmetics, Jewelry, Perfume, etc. Duty-free and Airport stores. Commercial Services: Banks, Insurance Companies and Utilities.

Performance Parameters

Light Source 617nm visible Red LED

Scan type Image linear CCD

Scan speed over 270times/second

Scan method Manually/Automatic inductive/Successive Scanning (Optional)

Scan Angle Yaw 65°,Pitch 55°,Rotation 30°

Precision 4mil

Depth of scan field 20-330mm

Bite Error 1/5million

Interfaces USB-HID,USB-COM, RS-232, PS2

Supported Symbologies EAN-8, EAN-13, UPC-A, UPC-E, CODE39, CODE93, CODE128, EAN128, Codebar, MSI, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, China Post Code, all 1D codes/LCD screen codes.

Physical Parameters

House Materail ABS+PC

Dimensions 200mm*66mm*65mm

Weight 223.9g

Cable Length 2m

Environmental Parameters

Operating Temperature -20℃-50℃

Storage Temperature -40℃-70℃

Relative Humidity 0~95%(Non-condensing)

Drop Resistance withstand multiple 3m drops onto concrete

Electronic Parameters

Voltage DC 5V±1%

Working Current 150mA

Features:

--can speed reach 270times per second

--Working with IOS and Android hardwares such as table and iPad

--Withstands multiple times 3 meters drops to concrete

--2500 point pixel ccd image sensor

--Interface USB, RS232, PS2can be used

Applications:

* Application fields: Non-food specialty stores such as Fashion Clothes, Cosmetics, Jewelry, Perfume, etc. Duty-free and Airport stores. Commercial Services: Banks, Insurance Companies and Utilities
