Zebex

Z-6082, Omni Direction, Laser Scanner,

Instant object-fly-by automatic wake-up
EAS compatible
Strict IP54 standards
Barcode stitching capable

The Z-6082 Laser Scanner:

The dual laser technology of the Z-6082 vertical scanner uses two laser diodes that scan in eight directions simultaneously and can scan 32 lines at a speed of 2400 scans per second.

High Performance:

Designed for high volume applications, ZEBEX's Z-SCAN + hardware decoding technology maximizes vertical scan performance.

Design Of Z-6082 Scanner:

The Z-6082 is housed in a rugged die-cast aluminum cube housing that is IP54 rated for splash and dust resistance.

Specifications:

Light Source
Dual 650 nm visible laser diodes (VLD)

Depth of Field
5 mil: 10 – 60 mm
7.5 mil: 0 – 150 mm
10 mil: 0 – 180 mm
13 mil: 0 – 200 mm
20 mil: 0 – 300 mm
Note: DOF may vary depending on environment condition and barcode quality.

Scan Lines
32

Scan Pattern
8 directions of scan field

Scan Rate
2, 400 scans per second

Print Contrast
30% @ UPC/EAN 100%

Indicator
Two-color LED (blue & red)

System Interface
Keyboard, RS-232, HID USB, USB Virtual COM, wand
