Datalogic

 3200VS, USB, Barcod Scanner,

  Image capture:

Illumix smart lighting technology reads barcodes from mobile phones or PDAs

Built to Last:

The Magellan 3200 VS Image Processor has reached a new level of reliability with the known quality and reliability of all Magellan products.

Software Management:

Special features not found in any other POS scanner include a microSD card reader to manage, update and maintain software. Software management is very flexible with the Magellan 3200 VS reader and includes many ways to download new software or modify existing configuration files and firmware.

Features:

Datalogic’s high performance Imaging Technology

Linear and 2D bar code reading

Solid-state electronics

Software driven - flexible and upgradeable

Micro SD card slot

Multiple interfaces in every unit

RS-232 auxiliary port

BARCODE:

Interface Type IBM 46xx/USB

Type stationary

Interface IBM 46xx, USB

Light Source Wave Length 625 nm

Barcodes Aztec code, Data Matrix, GS1 DataBar, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, MicroPDF417, PDF417, QR code

Print Contrast Signal (PCS) 25%

Max Working Distance 5.5 in

Skew (Degrees) 75

Pitch (Degrees) 65

Minimum Bar Width 5 mil

Features Checkpoint Electronic Article Surveillance (EAS), Micro SD card slot, deactivation of EAS tag

Decode Capability GS1 DataBar, QR code, MaxiCode, Aztec code, MicroPDF417, PDF417, Data Matrix, GS1 DataBar StackedOmnidirectional, GS1 DataBar Expanded Stacked

Scan Mode Fixed projection

OK Notification Beeper, LED indicator

Connectivity Technology Wired

Scan Element Type 2D imager

TTL Decoding Decoded

PRINTER:

Barcodes Aztec code, Data Matrix, GS1 DataBar, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked Omnidirectional, MaxiCode, MicroPDF417, PDF417, QR code

SCANNER

Type barcode scanner

Form Factor desktop

Scan Mode fixed projection

Scan Element Type 2D imager

ENVIRONMENTAL PARAMETERS:

Min Operating Temperature 32 °F

Max Operating Temperature 104 °F

Humidity Range Operating 5 - 95%

HEADER:

Brand Datalogic

Product Line Datalogic Magellan

Model 3200VSi

Packaged Quantity 1

Compatibility PC

INTERFACE REQUIRED:

Type USB

Total Qty 1

CABLE DETAILS:

Included Qty 1

Length 15 ft

DIMENSIONS & WEIGHT:

Width 5.6 in

Depth 6 in

Height 3.2 in

Weight 1.32 lbs

SLOT REQUIRED:

Type none

SERVICE & SUPPORT:

Type 3 years warranty

SERVICE & SUPPORT DETAILS:

Type limited warranty

Full Contract Period 3 years

GENERAL:

Manufacturer Datalogic
