HP J9663A Unmanaged Switch, 24 Port Fast Ethernet, 10/100 Mbps

HP J9663A - Description

Unmanaged Switch 24 Port Fast Ethernet, 10/100 Mbps

Compact and Versatile Network Solution:

HP J9663A is part of the HPE OfficeConnect 1410 Series, offering small businesses a dependable and easy-to-deploy network solution. This unmanaged Fast Ethernet switch features 24 autosensing 10/100 ports, ideal for simple plug-and-play connectivity in desktop, rack-mounted, or wall-mounted setups. Its compact design—measuring only three-quarters the width of a standard rack—makes it perfect for limited spaces. The metal enclosure ensures durability, and the included mounting hardware supports installation in EIA-standard 19-inch racks or under desks.

Performance-Optimized for Fast Data Transfer:

Engineered for solid network performance, the J9663A delivers a switching capacity of 4.8 Gb/s and supports up to 3.5 million packets per second (pps) for 64-byte packet transfers. With a latency of less than 11 microseconds, it ensures low delay, making it suitable for real-time applications such as VoIP and video conferencing. It includes an 8192-entry MAC address table and a 2MB packet buffer to handle simultaneous traffic across all ports efficiently.

Reliable Power and Energy Efficiency:

The unit is powered via an external power adapter that supports input voltage from 100-240V AC, with a low maximum power consumption of just 4.8 watts. It produces minimal heat dissipation at 17 BTU/hr and operates silently with a 0 dB acoustic output, making it suitable for noise-sensitive environments such as offices and meeting rooms.

Environmentally Resilient and Safe:

Built for durability, the HP J9663A switch operates in temperatures from 0ºC to 40ºC and can be stored in harsh conditions ranging from -40ºC to 70ºC. It’s designed to withstand relative humidity of up to 95% and altitudes of up to 10,000 feet. Certified for safety (UL, CSA, IEC, EN standards) and emissions compliance (FCC Class A), this switch ensures dependable and secure operation in diverse environments.
