Hikvision DS-3E0318P-E(B) Unmanaged PoE Switch, 18 Port Fast Ethernet with 2 Port Gigabit combo
Hikvision DS-3E0318P-E(B) - Description
Unmanaged PoE Switch, 18 Port Fast Ethernet with 2 Port Gigabit combo
Robust Power Management for Extended Longevity:
Hikvision DS-3E0318P-E(B) Unmanaged PoE Switch is engineered with intelligent PoE management to ensure reliable operation even under high-load conditions. When the total power demand surpasses the available power supply, the switch automatically manages and prioritizes power distribution to connected devices. This intelligent function not only prevents system overload but also contributes to the longevity of the switch by reducing unnecessary wear and tear on internal components, making it ideal for long-term deployments.
Extended Transmission Range Up to 300 Meters:
Designed specifically for video surveillance and IP camera networks, this PoE switch supports long-range data transmission. Ports 9 to 16 support up to 300 meters of transmission distance at 10 Mbps, more than doubling the standard 100-meter Ethernet limitation. This feature is essential for large-scale installations where cameras are distributed across a wide area, such as in parking lots, campuses, or industrial complexes.
Optimized for Efficiency and Reliability:
The DS-3E0318P-E(B) switch features an 8-core adaptive power supply that minimizes power loss across Ethernet cables. With a maximum PoE power budget of 230 W and support for IEEE 802.3af/at standards, each port can deliver up to 30 W. Moreover, its 6KV surge protection shields the switch from power spikes caused by lightning or electrical faults, ensuring consistent performance even in harsh environments.
High Performance with Prioritized Data Transmission:
Equipped with a switching capacity of 7.2 Gbps and a packet forwarding rate of 5.356 Mpps, this unmanaged switch delivers high-speed data forwarding for uninterrupted performance. Ports 1 to 8 are designated as high-priority VIP ports to guarantee reliable transmission of critical surveillance data, preventing delays during network congestion. This is especially beneficial for real-time video feeds and monitoring.
Durable Build and Wide Environmental Tolerance:
The switch is housed in a robust metal enclosure with compact dimensions of 440 mm × 44 mm × 220.8 mm and a net weight of 2.65 kg. It operates in extreme temperatures ranging from -10 °C to 55 °C, with a humidity tolerance of up to 95% (non-condensing), making it suitable for both indoor and outdoor deployments. The unit is compliant with multiple safety, EMC, and environmental standards, including FCC, CE, UL, and RoHS.
Ideal Choice for Surveillance and Network Expansion:
Whether you're setting up a new video surveillance system or expanding an existing network, the Hikvision DS-3E0318P-E(B) is a cost-effective and reliable solution. With 16 Fast Ethernet PoE ports and 2 Gigabit combo uplinks, this switch provides ample connectivity for IP cameras and NVRs, ensuring scalability and future-proofing your security infrastructure.
