D-Link NCB-C6UGRYR1-05 UTP Cat6 24AWG Patch Cord, 0.5M, Grey

D-Link NCB-C6UGRYR1-05 - Description

UTP Cat6 24AWG Patch Cord, 0.5M, Grey

High-Performance D-Link Cat6 Patch Cord for Seamless Networking:

D-Link NCB-C6UGRYR1-05 UTP Cat6 Patch Cord (0.5M, Grey) is a premium-quality Ethernet cable designed to deliver superior data transmission for high-speed networks. Ideal for LAN applications, this Cat6 patch cord supports 10BASE-T, 100BASE-TX Fast Ethernet, and 1000BASE-T (Gigabit Ethernet) standards, making it perfect for home, office, or data center use. It also supports Power over Ethernet (PoE) and advanced applications like 155/622 Mbps ATM and broadband video up to 550 MHz.

Durable Construction and Quality Materials:

Built with 4 pairs of unshielded twisted pair (UTP) 24 AWG bare copper conductors, the cable ensures efficient data flow with minimal signal interference. The insulation is made from high-density polyethylene (HD-PE), and the outer jacket is composed of flame-retardant PVC (UL94V-0), providing durability and heat resistance up to 75°C. Its flame-resistant properties meet VW-1 (UL) and FT-1 (CSA) standards for safety.

Reliable RJ-45 Connectors for Consistent Performance:

The D-Link patch cord features high-quality RJ-45 8P modular plugs with 30-micron gold plating for excellent conductivity and corrosion resistance. The contact blades are made of phosphor bronze for lasting durability. With a temperature operating range of -20°C to 80°C, 500V AC dielectric withstanding voltage, and 35M Ohm insulation resistance, this cable is engineered for robust and reliable connections.

Certified and Standards-Compliant Ethernet Cable:

This D-Link Cat6 cable is certified to meet and exceed TIA/EIA-568B.2, TIA/EIA-568C.2, and IEC 60603-7-4 standards. It's ETL verified, CUL listed, and RoHS compliant, ensuring top-tier performance and environmental safety. With 750 matching cycles and a cable-to-plug tensile strength of 20lbs (89N), this patch cord is built for long-term, high-demand use.
