D-Link Switch 24 Port 10/100 Unmanaged Rackmount with 2 Gigabit Ports / DES-1026G
D-Link Switch 24 Port 10/100 Unmanaged Rackmount with 2 Gigabit Ports / DES-1026G
- Twenty-four 10/100Mbps Fast Ethernet ports
- Two copper/SFP Gigabit combo ports
- Auto configuration of network
- Robust metal design with standard 19" rack-mount size
Enhanced Workgroup Performance and High Flexibility
The DES-1026G is an unmanaged 10/100 Mbps switch designed to enhance workgroup performance while providing a high level of flexibility. It provides 24 10/100Mbps ports for workstation connection, plus 2 copper/SFP Gigabit combo ports for server and uplink deployment, allowing a workgroup to multiply bandwidth, boost response time, and satisfy heavy load demands.
Increased Productivity
The DES-1026G comes with 24 10/100 Mbps ports, allowing a small workgroup to flexibly integrate to Ethernet and Fast Ethernet. These intelligent ports detect the network speed and auto-negotiate between 100BASE-TX and 10BASE-T, as well as between full and half-duplex, letting you focus on work-day productivity rather than connectivity issues.
Instantly Upgrade to Gigabit Speeds
Two copper/SFP Gigabit combo ports support auto-sensing and full/half-duplex auto negotiation, keeping you up to date with the latest technologies in switch connectivity. Additionally, all ports support flow control, which minimizes dropped packets by sending out collision signals when the port’s receiving buffer is full, ensuring reliable connectivity.
Plug and Play
All ports support auto-negotiation of MDI/MDIX crossover, which eliminates the need for crossover cables or uplink ports. Any port can simply plug to a workstation, a server, a hub or a switch using the usual straight-through twisted-pair cable, saving you time and money. With 26 plug-and-play ports, the switch is a perfect choice for workgroups to upgrade performance in a client/server environment. The ports can be connected to workstations and servers in full duplex, or hubs in half-duplex.
Specifications
| 100Base-TX Interface | 24 |
|---|---|
| Auto MDI/MDIX | Yes |
| Switching Capacity | 8.8 Gbps |
| Max. Packet Forwarding Rate | 0.1488 Mpps |
| Store & Forwarding Forwading | Yes |
| Dimension | 440 x 140 x 44 mm |
| Weight | 1.836 kg |
| Operation Temperature | 0 ~ 40°C |
| Storage Temperature | -10 ~ 70 °C |
| Operation Humidity | 10% ~ 90% |
| Storage Humidity | 5% ~ 95% |
| Maximum Power Consumption | 6.6 Watts |
| Standby Power Consumption | 3.25 Watts |
| Maximum Heat Dissipation | 22.8 BTU/h |
| MTBF | 652,038 hours |
| Packet Buffer Size | 512K Bytes |
| FAN | Fanless |
| Power Saving By Link Status | Yes |
| MAC Address Table Size | 8K |
