D-LINK KVM-440 8 Port PS2 USB Combo KVM Switch

D-LINK, KVM-440, 8 Port, PS2, USB, Combo, KVM, Switch,

D-Link’s KVM switches are the ideal solution for data centers and other businesses where a large number of servers need to be managed from a single location. A large number of computers can be accessed from a single console, switching between them using the front panel buttons, keyboard hotkeys, or Onscreen Display (OSD) menu.

Versatile Management:

Toggle between clients using the front panel buttons, keyboard hotkeys, or On-screen Display (OSD) menu. The on-screen menu allows you to label each channel with a descriptive name, providing clear and easy navigation. A convenient Auto-Scan function allows you to automatically toggle between multiple computers sequentially at preset intervals. The front panel LEDs assist with workstation/server status monitoring. Green LEDs indicate that systems are online, while separate red LEDs indicate when a particular system has been selected for management via console.

Convenient Installation:

The sturdy metal chassis is mountable in a standard 19-inch rack. Daisy chain multiple KVM switches together up to three levels deep; cascaded units require no special configuration and automatically configure themselves as master or slave. Target workstations can be connected via keyboard/mouse or PS/2 using a custom combo cable. A PS/2 or USB keyboard is emulated on each terminal allowing all attached computers to successfully boot without keyboard errors. Hot-pluggable connections allow you to add devices to or remove them from the KVM switch without the need to shut it down.

Features:

Number of Computers Controlled
• 8

Selection Method
• Push Button and Hot-Key (PS/2 Keyboard) or On-Screen-Display (OSD)

LEDs
• Red for PC Selection
• Green for PC Online/Ready

PC Connectors
• Video: 8 x HDB-15 female
• Keyboard/Mouse: PS/2 & USB Signal Combined

Console Ports
• Keyboard: 1 x 6 pin mini-DIN female
• Mouse: 1 x 6 pin mini-DIN female
• Video: 1 x HDB-15 female

Firmware Upgrade Port
• Mini USB

Auto-Scan Interval
• Adjustable time setting by OSD menu

DDC, DDC2 monitor
• Maximum resolution up to 2048 x 1536 @ 65 Hz

Hot-swappable
• Yes

Operating Systems Supported
• Windows 98SE/ME/2000/2003/2008/XP/Vista/7, Linux, Mac OS 9/OS X, Sun Microsystems

Physical Parameters
Power
• By external power adapter

Dimensions (L x W x H)
• 44 x 15.7 x 4.5 cm

Weight
• 1750 g

Housing Material
• Metal

Operating Temperature
• 0 to 50В°C

Humidity
• 0% to 80% Relative Humidity

Certifications
• FCC, CE, C-Tick, IC, CSA

Standard package contents
• Four 1.8 m cables
