Vertiv Liebert GXT5-16KIRT9UXLE​ On-Line UPS, 16000VA/16000W, Rack/Tower

GXT5-16KIRT9UXLE
188,858 EGP
Out of stock
Reward points: 94429 points
Get a quote
Call Us
Chat us on Whatsapp
Payment Methods
  • Brand: Vertiv
  • Model: GXT5-16KIRT9UXLE
  • Power range: 16000VA/16000W
  • Battery Voltage/ Capacity: 12V/9Ah
  • Battery Quantity: supported 32 batteries
  • Weight (kg): 135.2kg
  • Warranty: 1 Year
Brand:
Vertiv
U.P.S Specifications
Part Number
GXT5-16KIRT9UXLE
U.P.S Configuration
Rack/Tower
Rating (VA/Watts)
16000VA/16000W
INPUT SYSTEM
288 VAC
OUTPUT SYSTEM
230 V
rated voltage
16000VA
LCD DISPLAY
LCD
BATTERIES VOLTAGE
12V/9Ah
Battery quantity
32
Dimensions
430 x 630 x 394mm
Weight (kg)
135.2kg
Warranty
1 Year

Vertiv Liebert GXT5-16KIRT9UXLE On-Line UPS - Description

16000VA/16000W, Rack/Tower

Unmatched Power Protection for Critical Equipment:

Vertiv Liebert GXT5-16KIRT9UXLE is a high-performance uninterruptible power supply (UPS) designed to safeguard critical systems from power outages and disturbances. This 16kVA online double-conversion UPS ensures continuous power conditioning and is perfect for centralized and edge locations. With a unity power factor (1.0), it supports more connected loads while optimizing space and cost efficiency. The system’s ENERGY STAR 2.0 certification reinforces its commitment to energy efficiency and sustainability.

Vertiv Liebert GXT5-16KIRT9UXLE

Flexible Tower/Rack Mount Design with Scalable Runtime:

This UPS features a versatile tower/rack-mountable 9U form factor, offering adaptability for various installation needs. Its scalable runtime capability is enabled by External Battery Cabinet (EBC) autodetection, providing extended backup time during outages to keep mission-critical systems operational. At 100% load, the UPS delivers 3.5 minutes of runtime, extendable to 10 minutes with an additional battery cabinet. For lighter loads (50%), the runtime increases significantly to 26.5 minutes.

Advanced Communication and Monitoring Capabilities:

The Vertiv UPS is equipped with a built-in Vertiv RDU101 communications card and supports Vertiv Power Insight software, enabling remote monitoring and management. This feature allows users to make informed decisions and quickly resolve events. Its user-friendly color/graphic LCD interface provides real-time status updates, including battery health monitoring. Additional connectivity options include serial ports, USB (HID compliant), and optional Power Output Distribution (POD) modules with IEC outlet receptacles.

GXT5-16KIRT9UXLE On-Line UPS

Robust Power Performance and Efficiency:

Operating at 230VAC input and output, the Vertiv UPS offers a voltage range of 176VAC to 288VAC, supporting both single-phase and three-phase input wiring. It delivers pure sinewave output for stable and reliable power. The UPS is engineered to handle overload conditions, supporting up to 150% load for 200 milliseconds. Its auto-sensing frequency range (40Hz to 70Hz) and optimized efficiency ensure superior performance under varied conditions.

Environmentally Friendly and Built to Last:

This UPS is environmentally conscious, compliant with RoHS and REACH standards. It operates reliably within a wide temperature range of 0°C to 40°C and at elevations up to 3,000 meters. With a robust build and sound emissions of less than 58dB, it ensures a quiet and durable solution for sensitive environments.

Compact, High-Capacity Solution for Modern Needs:

Weighing 135.2 kg, the Vertiv Liebert UPS combines compact design with robust performance, making it ideal for data centers, healthcare, and edge computing applications. Its reliable valve-regulated lead-acid batteries and customizable configurations make it a preferred choice for businesses prioritizing uptime and efficiency. Backed by a 1-year limited warranty, it ensures peace of mind and dependable power continuity.

Vertiv GXT5-16KIRT9UXLE UPS
