Brand :
UNV
Part Number
IPC322LB-SF28(40)-A
Camera Technology
IP CAMERA
Indoor / outdoor
INDOOR
Camera
Sensor
1/2.8", 2.0 megapixel, progressive scan, CMOS
Lens
2.8mm@F1.6
DORI Distance Lens (mm)
2.8
DORI Distance Detect (m)
43.4
Angle of View (H)
106.7°
Angle of View (V)
57.1°
Adjustment angle
Pan: 3° ~ 360°
Shutter
Auto/Manual, 1 ~ 1/100000s
Minimum Illumination
Colour: 0.002Lux ( F1.6, AGC ON) 0Lux with IR
Day/Night
IR-cut filter with auto switch (ICR)
Digital noise reduction
2D/3D DNR
IR Range
Up to 30m (98ft) IR range
Wavelength
850nm
IR On/Off Control
Auto/Manual
Defog
Digital Defog
WDR
120dB
Video
Video Compression
Ultra 265, H.265, H.264, MJPEG
H.264 code profile
Baseline profile, Main profile, High profile
Frame Rate
Main Stream: 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps Sub Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
Video Bit Rate
128 Kbps~6 Mbps
OSD
Up to 4 OSDs
Privacy Mask
Up to 4 areas
ROI
Up to 8 areas
Motion Detection
Up to 4 areas
White Balance
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction
2D/3D DNR
Smart IR
Supported
Flip
Normal/Vertical/Horizontal/180°
Dewarping
N/A
HLC
Supported
BLC
Supported
Smart
Behavior Detection
Cross line, intrusion(based on human body detection)
General Function
Watermark, IP address filtering, access policy, ARP protection, RTSP authentication, user authentication, HTTP authentication
Network
Protocols
IPv4, IGMP, ICMP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, UPnP, HTTP
Compatible Integration
ONVIF (Profile S, Profile G, Profile T), API
Client
EZStation, EZView, EZLive
Web Browser
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Audio
Audio Compression
G.711
Suppression
Supported
Sampling Rate
8KHZ
Interface
Built-in Mic
Supported
Built-in Speaker
Supported
Network
10/100M Base-TX Ethernet
Storage
Edge Storage
Micro SD, up to 128 GB
Network Storage
ANR,NAS(NFS)
General
Power
DC 12V±25%, PoE (IEEE 802.3af)
Power consumption
Max 8.0W
Dimensions (Ø x H)
Φ118 x 95mm (Φ4.6” x 3.8”)
Net Weight
0.30kg (0.66lb)
Material
Metal + Plastic
Working Environment
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Strorage Environment
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Surge Protection
4KV
Ingress Protection
IP67
Reset Button
N/A
UNV IPC3612LE-ADF28KMC-WL
2MP HD Color Hunter IR Fixed Eyeball Network Camera
High quality image with 2MP, 1/2.8"CMOS sensor
2MP (1920*1080) @30/25fps; 720P (1280*720) @30/25fps;
Ultra 265, H.265, H.264, MJPEG
120dB true WDR technology enables clear image in strong light scene
Support 9:16 Corridor Mode
Built-in Mic & Speaker
Smart IR, up to 30m (98ft) IR distance
White Light, up to 30m (98ft) white light distance
Supports 128 G Micro SD card
IP67 protection
Support PoE power supply
3-Axis
