UNV IPC2322LB-ADZK-G 2MP IR VF Bullet IP Camera

IPC2322LB-ADZK-G
  • Brand: UNV
  • Model: IPC2322LB-ADZK-G
  • Sensor: 1/2.7" Progressive Scan CMOS
  • Maximum Resolution: 2MP
  • Frame Rate: up to 30fps
  • Lens: 2.8–12mm motorized varifocal lens with autofocus
  • Day&Night: IR-cut filter with auto switch (ICR)
  • Angle Adjustment: Pan: 0° ~ 360°, Tilt: 0° ~ 90°, Rotate: 0° ~ 360°
  • Audio: Built-in microphone
  • Storage: MicroSD card support up to 128GB
Get a quote
Call Us
Chat us on Whatsapp
Payment Methods
Brand:
UNV
Part Number
IPC2322LB-ADZK-G
Camera Technology
IP CAMERA
Warranty
1 Year
Indoor / outdoor
OUTDOOR
Camera
Frame Rate
up to 30fps
Night Vision
up to 50m
Resolution
2MP
Sensor
1/2.7", 2.0 megapixel, progressive scan, CMOS
Lens
2.8 ~ 12mm, AF automatic focusing and motorized zoom lens
DORI Distance Lens (mm)
2.8
DORI Distance Detect (m)
42.0
DORI Distance Identify (m)
4.2
DORI Distance Observe (m)
16.8
DORI Distance Recognize (m)
8.4
Angle of View (H)
108.05°~ 32.59°
Angle of View (O)
111.91°~36.53°
Angle of View (V)
56.81°~ 18.36°
Adjustment angle
Pan: 3° ~ 360°
Shutter
Auto/Manual, 1 ~ 1/100000s
Minimum Illumination
Colour: 0.01Lux ( F2.0, AGC ON) 0Lux with IR
Day/Night
IR-cut filter with auto switch (ICR)
Digital noise reduction
2D/3D DNR
IR Range
Up to 50m (164ft) IR range
Wavelength
850nm
IR On/Off Control
Auto/Manual
Defog
Digital Defog
WDR
120dB
Video
Video Compression
Ultra 265, H.265, H.264, MJPEG
H.264 code profile
Baseline profile, Main profile, High profile
Frame Rate
Main Stream: 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps Sub Stream: 720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps;
Video Bit Rate
128 Kbps~6144 kbps
OSD
Up to 4 OSDs
Privacy Mask
Up to 4 areas
ROI
Up to 8 areas
Motion Detection
Up to 4 areas
White Balance
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction
2D/3D DNR
Smart IR
Supported
Flip
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise
Dewarping
N/A
HLC
Supported
BLC
Supported
Network
Protocols
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL, SNMP
Compatible Integration
ONVIF (Profile S, Profile G, Profile T), API
Client
EZStation, EZView, EZLive
Web Browser
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Audio
Audio Compression
G.711
Suppression
Supported
Sampling Rate
8KHZ
Interface
Built-in Mic
Supported
Network
10/100M Base-TX Ethernet
Storage
Edge Storage
Micro SD, up to 128 GB
Network Storage
ANR,NAS(NFS)
General
Power
DC 12V±25%, PoE (IEEE 802.3af)
Power consumption
Max 8.5W
Dimensions (Ø x H)
206 × 74 × 74mm (8.1” × 2.9” × 2.9”)
Net Weight
0.54kg (1.19lb)
Material
Metal
Working Environment
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Strorage Environment
-30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing)
Surge Protection
6KV
Ingress Protection
IP67
Reset Button
Supported

UNV IPC2322LB-ADZK-G - Description

2MP IR VF Bullet IP Camera

Reliable Outdoor Surveillance with UNV IPC2322LB-ADZK-G:

The UNV IPC2322LB-ADZK-G 2MP IR VF Bullet IP Camera is designed to deliver dependable security monitoring for homes, offices, warehouses, and outdoor environments. Equipped with a 2MP progressive scan CMOS sensor, the camera captures clear Full HD video at 1920×1080 resolution with smooth frame rates up to 30fps. This ensures detailed footage for both live monitoring and recorded playback. The camera supports advanced video compression technologies such as Ultra 265, H.265, H.264, and MJPEG, which help reduce bandwidth usage and storage requirements while maintaining excellent image quality.

UNV IPC2322LB-ADZK-G

Flexible Motorized Zoom Lens for Wide Coverage:

One of the standout features of this camera is its 2.8–12mm motorized varifocal lens with autofocus. This allows users to adjust the field of view from a wide area to a more focused scene without physically moving the camera. With horizontal viewing angles ranging from 108.05° to 32.59°, it can cover large spaces like parking lots or narrow monitoring zones such as entrances and corridors. The DORI distance performance also supports long-range detection and identification, making it suitable for professional surveillance setups.

UNV Camera

Enhanced Image Clarity in Challenging Lighting:

The camera integrates 120dB True WDR (Wide Dynamic Range), ensuring clear images even in scenes with strong backlighting or high contrast. In addition, Smart IR technology provides night vision up to 50 meters, allowing reliable monitoring in complete darkness. Digital noise reduction (2D/3D DNR), digital defog, and advanced image processing further enhance clarity in difficult weather or lighting conditions.

surveillance camera

Smart Detection and Secure Network Integration:

This IP camera includes intelligent security features such as intrusion detection, cross-line detection based on human body detection, motion detection, and tampering alarms. Built-in microphone support enables audio recording for more comprehensive surveillance. With ONVIF compatibility and support for multiple network protocols, the device integrates easily with NVR systems and surveillance software.

IP Camera
