Hikvision DS-QAE0203G1-V 3W Analog Ceiling Speaker

Hikvision DS-QAE0203G1-V - Description

3W Analog Ceiling Speaker

The Hikvision DS-QAE0203G1-V 3W Analog Ceiling Speaker is a compact and reliable audio solution designed for public address and background music applications. Engineered with Hikvision’s proven quality standards, this ceiling-mounted speaker delivers clear, balanced sound while maintaining a discreet and modern appearance. It is ideal for use in offices, retail stores, hotels, schools, hospitals, and other commercial or institutional environments where consistent audio coverage is essential.

Clear and Balanced Audio Performance:

Despite its compact size, the DS-QAE0203G1-V offers impressive sound clarity. With a rated power of 3W and sensitivity of 91 dB ±3 dB, it ensures efficient audio output with minimal distortion. The frequency response of 90 Hz to 20 kHz allows it to reproduce both speech and background music accurately, making announcements clear and intelligible. Its maximum acoustic pressure of 95 dB ensures sufficient volume for small to medium indoor spaces.

Wide Coverage for Uniform Sound Distribution:

The speaker features a 5.25-inch full-range speaker unit and a conical coverage angle of 95°, providing even sound dispersion across the listening area. This wide coverage minimizes audio dead zones and reduces the need for multiple speakers in smaller rooms. As a result, it is a cost-effective choice for ceiling audio systems that require consistent sound quality throughout the space.

Durable Design and Professional Finish:

Built with a high-quality ABS shell and a robust iron mesh grille, the DS-QAE0203G1-V is designed for long-term durability. Its clean white finish blends seamlessly with most ceiling designs, maintaining a professional and unobtrusive look. The speaker is also engineered to operate reliably in demanding environments, with an operating temperature range of -20°C to 50°C and humidity tolerance of up to 95%.

Easy Installation and System Compatibility:

Designed for 100V audio systems, this analog ceiling speaker integrates easily with standard public address and background music systems. The Ø148 mm mounting hole and compact dimensions (Ø170 × 64 mm) make installation quick and convenient. With a lightweight design of approximately 435 g, it reduces strain on ceiling structures while ensuring secure mounting.

Ideal Choice for Commercial Audio Applications:

The Hikvision DS-QAE0203G1-V 3W Analog Ceiling Speaker is an excellent choice for users seeking reliable performance, easy installation, and professional sound quality. Its balanced audio output, wide coverage, and durable construction make it a dependable solution for modern indoor audio installations, fully aligned with commercial and security-focused audio system requirements.
