Asus Rog Strix Z590-E Gaming WiFi LGA1200 DDR4 ATX Motherboard

Asus Rog Strix Z590-E Gaming WiFi - Description

LGA1200 DDR4 ATX Motherboard

Premium Platform for 10th & 11th Gen Intel Processors:

The ASUS ROG Strix Z590-E Gaming WiFi is a premium ATX motherboard built for high-end gaming and productivity, designed to support Intel LGA1200 10th and 11th Gen Core, Pentium Gold, and Celeron processors. Featuring the Intel Z590 chipset, it delivers PCIe 4.0 support for ultra-fast data transfer across multiple high-speed interfaces. The board is equipped with a robust 14+2 power stage VRM design, ProCool II power connector, premium alloy chokes, and durable capacitors, ensuring stable power delivery for demanding multi-core CPUs.

Advanced Thermal Design for Sustained Performance:

Engineered for optimal thermal performance, it includes an enhanced cooling solution with VRM and I/O heatsinks, an L-shaped heat pipe, four M.2 heatsinks, and a backplate for the primary PCIe 4.0 M.2 slot to prevent throttling. Connectivity is top-tier, offering onboard Intel WiFi 6E (802.11ax) via the AX210 module, dual 2.5 Gb Ethernet ports with ASUS LANGuard, HDMI 2.0 and DisplayPort 1.4 for integrated graphics output, four M.2 NVMe slots, and a USB 3.2 Gen 2x2 Type-C port.

AI-Driven Optimization for Performance and Efficiency:

The motherboard integrates ASUS-exclusive AI technologies, AI Overclocking, AI Cooling, AI Networking, and Two-Way AI Noise Cancelation—to intelligently optimize system performance, cooling, network traffic, and audio clarity. User-friendly features like M.2 Q-Latch, pre-mounted I/O shield, BIOS FlashBack™, Clr CMOS button, Q-Code display, and FlexKey enhance the DIY experience.

Intuitive Software and Diagnostic Tools:

Customization is elevated with Aura Sync RGB lighting, including addressable Gen 2 headers for synchronized illumination across compatible components. Audio quality is exceptional, powered by the ALC4080 codec and Savitech SV3H712 amplifier, enhanced by DTS® Sound Unbound and Sonic Studio III for immersive audio. The package also includes a 60-day AIDA64 Extreme subscription and an intuitive UEFI BIOS with integrated MemTest86, making tuning and diagnostics seamless for users of all levels.

Performance:

ASUS ROG Strix Z590-E Gaming WiFi delivers exceptional performance through a combination of advanced power delivery, cutting-edge connectivity, and optimized hardware support. Built for Intel Socket LGA1200, it fully supports 10th and 11th Gen Intel® Core™ processors with a robust 14+2 power stage VRM design and ProCool II power connector for enhanced conductivity, durability, and stable power delivery under heavy loads. Performance is further maximized with PCIe 4.0 support via two reinforced SafeSlots—configurable as x16 or x8/x8 for multi-GPU SLI® setups—alongside an additional PCIe 3.0 x16 slot running at x4. Memory performance is optimized with four DIMM slots supporting dual-channel DDR4 speeds of up to 5333 MHz+ via overclocking, enhanced by ASUS’s OptiMem II technology for improved signal integrity and stability.

Connectivity:

ASUS ROG Strix Z590-E Gaming WiFi offers a wide range of high-speed and versatile connectivity options to meet the demands of gamers, creators, and power users. It features rich A/V output with HDMI 2.0 and DisplayPort 1.4, enabling support for high-resolution displays and 4K@60Hz output. The I/O panel includes multiple USB ports: four USB 3.2 Gen 1, three USB 3.2 Gen 2 (including two Type-A and one Type-C), and a blazing-fast USB 3.2 Gen 2x2 Type-C® port delivering up to 20 Gbps for rapid data transfers. Additional internal and rear USB headers support expansion, including a dedicated USB 3.2 Gen 2x2 Type-C connector.
