D-Link 18-Port Gigabit Smart Managed PoE Switch 16 PoE 2 Combo RJ45/SFP ports (130W PoE budget) / DGS-1100-18PV2
D-Link, 18-Port Gigabit, Smart Managed, PoE, Switch, 16 PoE, 2 Combo, RJ45/SFP ports, (130W PoE budget), DGS-1100-18PV2,
- 16 x 10/100/1000BASE-T PoE+ ports
- 2x RJ45/SFP Combo ports
- PoE+ support with up to 30W per port
- 130 Watts PoE Power Budget
- Bandwidth Control ensures latency-sensitive traffic always gets the bandwidth it needs
- Quality of Service further prioritizes latency-sensitive traffic, ensuring timely delivery
- Segregate different types of traffic, such as surveillance or voice, with VLANs to heighten security
- IGMP Snooping sends multicast traffic only where it needs to go, significantly cutting down network traffic
- Innovative energy saving features are good for your budget, as well as the environment
- Get up and going quickly with streamlined first-time setup and ongoing management
Powerful Switching for your Business
The DGS-1100 Series is a range of powerful switches that offer a lot of bang for your buck. They are great for busy SMBs who expect a lot of their network, including support for surveillance and VoIP. They are packed with traffic management & optimization features that keep your network congestion free. Meanwhile, management tools are flexible and intuitive, making your life easier.
Gigabit Ethernet Speeds
Take your Ethernet speeds to the next level with Gigabit Connectivity.
Cutting Edge Green Technology
Innovative D-Link Green power saving features keep your budget in check.
Manage Anywhere, Anytime
Remote setup & management is easy, and can be done from anywhere.
Easy to Use & Easy to Install
D-Link Network Assistant Utility (DNA) can quickly discover and do initial setup for D-Link Networking devices such as the DGS-1100 Series, which greatly improves efficiency for solution deployment.
VLANs: Stronger Security & Better Traffic Management
Relatively easy to set up, VLANs can be a big boon for your network. They can isolate sensitive areas of your network, keeping them safe from those with malicious intent, or keeping bandwidth open for latency-sensitive traffic such as VoIP.
For Voice
If VoIP calls make up a large slice of your network usage, separating them onto their own VLAN can ensure they get the bandwidth they need for smooth conversations without lag or jitters.
For Surveillance
If you have surveillance cameras and devices attached to your network, putting them onto their own VLAN keeps surveillance footage running seamlessly. At the same time, it can help prevent a variety of malicious attacks by restricting access to different network areas.
Green Technology
D-Link Green technology enables the DGS-1100 Smart Managed Switches to save power without sacrificing performance. Most of the models in the series utilize a fanless design, for silent and energy-efficient operation. All are IEEE 802.3az-compliant and feature Link Status detection and Time-Based PoE.
PD Alive Actively Mitigates Downtime
Round-the-clock surveillance footage is vital. If you have Cameras attached to your network,
you may have thought technical difficulties were a given. However, the PD-Alive feature actively mitigates device downtime. If a device is not working as expected, the Switch can automatically reset them and get them back online. No need to turn them on and off again in the middle of the night.
Specifications:
Static Routing : | No |
Types of ports : | SFP Ports|Gigabit Ports |
Built-in PSU : | Yes |
Switch Series : | DGS-1100 Series |
Number of Ports : | 5 - 16 |
PoE Type Required : | PoE|PoE+ |
Type of Port Required : | Gigabit Copper|Gigabit Fibre |
Design : | Desktop|Rackmountable |
High Speed Stacking : | No |
Switch Type : | Layer 2 |
Cable Diagnostics : | Yes |
Command Line Interface : | No |
Dimensions (Size) : | 280 x 230 x 44 mm |
Energy Saving Technology : | EEE Compliant|RoHS 6 Compliant |
Fans : | 1 |
IGMP Snooping : | Yes |
Jumbo Frame : | 9216 bytes |
Link Aggregation : | Yes |
PoE Budget : | 130 Watts |
PoE ports : | 16 Ports |
QoS : | Yes |
19" Rack Mountable : | Yes |
SFP ports : | 2 Ports (Combo) |
Spanning Tree Protocol : | Yes |
Surveillance VLAN : | Yes |
Switching Capacity : | 36 Gbps |
1000Base-T ports : | 16 Ports |
VLAN : | 4K Groups |
Voice VLAN : | Yes |
Web-based GUI : | Yes |
