Intel Core i5-14400F

Desktop Processor

Intel Core i5-14400F, part of Intel’s 14th generation lineup, is designed to deliver powerful performance for desktop applications. Codenamed Raptor Lake, this Desktop Processor offers a balanced mix of performance and efficiency cores, making it suitable for a range of computing tasks from gaming to content creation.

Core Specifications and Performance:

The Intel Core i5-14400F boasts a total of 10 physical cores, divided into 6 performance cores and 4 efficient cores, supporting a total of 16 threads. The performance cores can turbo boost up to 4.7 GHz, while the efficient cores reach up to 3.5 GHz, providing a robust performance boost when needed. With a base power of 65W and a maximum turbo power of 148W, the i5-14400 is designed for efficient energy usage without compromising on power.

Advanced Cache and Memory Support:

This Desktop Processor features 20 MB of Intel® Smart Cache and 9.5 MB of L2 cache, ensuring quick access to frequently used data and instructions. It supports a maximum memory size of 192 GB, compatible with DDR5 memory up to 4800 MT/s and DDR4 memory up to 3200 MT/s. With a dual-channel memory architecture and a maximum memory bandwidth of 76.8 GB/s, the i5-14400Fensures smooth and responsive multitasking capabilities.

Integrated Graphics Capabilities:

Processor supports a wide range of display outputs including eDP 1.4b, DP 1.4a, and HDMI 2.1. It can handle a maximum resolution of 4096 x 2160 at 60Hz via HDMI and 7680 x 4320 at 60Hz via DisplayPort, making it suitable for high-definition displays and multiple monitor setups. The integrated graphics also support DirectX 12, OpenGL 4.5, and OpenCL 3.0, providing ample power for everyday graphics needs and light gaming.

Expansion and Connectivity Options:

The i5-14400F supports PCI Express 5.0 and 4.0, with configurations up to 1x16+4 or 2x8+4, and a maximum of 20 PCI Express lanes. This ensures compatibility with the latest high-speed components and peripherals, enhancing the overall system performance. The Desktop Processor also features Direct Media Interface (DMI) 4.0 with up to 8 lanes, allowing for fast communication between the intel processor and other system components.

Package and Thermal Specifications:

This intel processor is compatible with the FCLGA1700 socket and comes in a package size of 45.0 mm x 37.5 mm. It supports a maximum operating temperature of 100°C, with an advanced thermal solution specification of PCG 2020C, ensuring efficient heat dissipation and maintaining optimal performance under heavy workloads.

Advanced Technologies and Security Features:

The Intel Core i5-14400F incorporates several advanced technologies such as Intel® Gaussian & Neural Accelerator 3.0, Intel® Thread Director, and Intel® Deep Learning Boost, enhancing AI and machine learning capabilities. It also supports Intel® Turbo Boost Technology 2.0, Intel® Hyper-Threading Technology, and various instruction set extensions, including Intel® SSE4.1, SSE4.2, and AVX2. For security, the intel processor includes features like Intel® Control-Flow Enforcement Technology, Intel® AES New Instructions, Secure Key, and Intel® Boot Guard, ensuring robust protection against various threats.
